Nitrous oxide and oxygen flow meters

Nitrous oxide and oxygen flow meters as part of a Boyle’s apparatus used for anaesthesia. The position of the float in the graduated tubing goes up as the flow increases.

1. Nitrous oxide pressure guage
2. Boyle’s machine
3. Oxygen pressure guage
4. Halothane delivery device
